ADLER 3 Flute Corner Radius Endmill For Aluminium
WC=90 Co=10 HV30=1571 TRS Min=4000N/mm² HRA=91.8 Grain Size 0.6 µm
.png)
HRC | Dia(d) | Radius(R) | Total Length(L) | Cutting Length(l) | Shank Dia(D) | Flute(Z) |
50/55 | 1 | 0.2 | 50 | 3 | 4 | 4 |
50/55 | 1.5 | 0.2 | 50 | 4.5 | 4 | 4 |
50/55 | 2 | 0.2, 0.5 | 50 | 6 | 4 | 4 |
50/55 | 2.5 | 0.2, 0.5 | 50 | 7.5 | 4 | 4 |
50/55 | 3 | 0.2,0.5,1 | 50 | 9 | 4 | 4 |
50/55 | 3 | 0.2,0.5,1 | 50 | 9 | 4 | 4 |
50/55 | 4 | 0.2,0.5,1 | 50 | 12 | 4 | 4 |
50/55 | 4 | 0.2,0.5,1 | 75 | 16 | 4 | 4 |
50/55 | 4 | 0.5,1 | 100 | 20 | 4 | 4 |
50/55 | 5 | 0.2,0.5,1 | 50 | 15 | 5 | 4 |
50/55 | 5 | 0.2,0.5,1 | 50 | 15 | 6 | 4 |
50/55 | 6 | 0.2,0.5,1 | 50 | 18 | 6 | 4 |
50/55 | 6 | 0.2,0.5,1 | 75 | 24 | 6 | 4 |
50/55 | 6 | 0.5,1 | 100 | 40 | 6 | 4 |
50/55 | 8 | 0.2,0.5,1,2 | 60 | 24 | 8 | 4 |
50/55 | 8 | 0.5,1 | 75 | 32 | 8 | 4 |
50/55 | 8 | 0.5,1 | 100 | 40 | 8 | 4 |
50/55 | 10 | 0.2,0.5,1,2 | 75 | 30 | 10 | 4 |
50/55 | 10 | 0.5,1,2 | 100 | 40 | 10 | 4 |
50/55 | 12 | 0.5,1,1.5,2 | 75 | 36 | 12 | 4 |
50/55 | 12 | 0.5,1,2 | 100 | 45 | 12 | 4 |
